ATOM 01033371 (HV1400) Flashcut Oscillating Knife Blade|Manufacturer of Carbide Knives & Blades

ATOM 01033371 (HV1400) Tungsten Carbide Flashcut Replacement Oscillating Knife Blade for ATOM Cutting Systems

Tungsten carbide oscillating knife blade for ATOM cutting systems

ATOM 01033371 (HV1400) Flashcut replacement blade

Flat oscillating blade design for accurate cutting

28 mm knife height for controlled oscillation

Supports up to 10.0 mm maximum cutting depth

65° cutting angle for clean and precise cuts

Flat 0.63 mm mounting compatible with ATOM oscillating tools

OEM-compatible replacement blade for ATOM machines

Request A Quote

Description
Related Products

Product Specification Sheet

Item	Specification
Cutter Brand	ATOM
Model	01033371 (HV1400)
Knife Type	Flat, Flat Oscillating Blades, Oscillating Blade
Knife Height	28.00 mm
Knife Width	5.50 mm
Thickness	0.63 mm
Max. Cutting Depth	10.00 mm
Cutting Angle	65°
Knife / Blade Mounting	Flat 0.63 mm
Replacement	Yes

Product Description

The ATOM 01033371 (HV1400) Oscillating Knife Blade is a tungsten carbide Flashcut replacement blade developed for ATOM digital and automated cutting systems. This flat oscillating knife blade is designed to deliver precise cutting performance and consistent edge quality in packaging and leather processing applications.

With a 28 mm knife height and a maximum cutting depth of 10.0 mm, the ATOM HV1400 oscillating blade is suitable for controlled medium-depth cutting tasks. The 0.63 mm blade thickness allows smooth oscillation with high cutting accuracy, while the 65° cutting angle supports clean penetration and stable cutting paths.

Manufactured from tungsten carbide, the ATOM 01033371 oscillating knife blade offers excellent wear resistance and cutting stability. The flat 0.63 mm mounting ensures secure installation and quick replacement on ATOM Flashcut oscillating knife tool holders, making it an OEM-compatible replacement blade for automated cutting workflows.
