ATOM 01040917 Flashcut Oscillating Knife Blade for CNC Cutters|Manufacturer of Carbide Knives & Blades

ATOM 01040917 Flashcut Oscillating Knife Blade for CNC Cutters

Flashcut oscillating knife blade for CNC cutters

Made from tungsten carbide for durability and edge retention

17 mm maximum cutting depth

Low-angle design for smooth, controlled cutting

Flat 1 mm mounting for stable oscillation

Designed for multi-material applications

Request A Quote

Description
Related Products

ATOM 01040917 Flashcut Oscillating Knife Blade for CNC Cutters

Technical Specifications

Specification	Details
Model	ATOM 01040917
Knife Type	Flat / Oscillating Blade
Blade Material	Tungsten Carbide
Compatible Brand	Atom
Mounting	Flat 1 mm
Max Cutting Depth	17 mm
Knife Height	33 mm
Knife Width	5.5 mm
Thickness	1.0 mm
Angle	0° – 4°30'
Replacement	Yes
Materials	Foam board, Leather, Rubber, Synthetic materials, Textiles

The ATOM 01040917 Flashcut oscillating knife blade is designed for stable and precise cutting across a wide range of soft and semi-soft materials on CNC digital cutting systems.

Manufactured from high-quality tungsten carbide, this oscillating knife blade delivers excellent wear resistance, edge stability, and long service life, making it suitable for continuous industrial use.

With a maximum cutting depth of 17 mm and a low-angle cutting geometry (0°–4°30'), the ATOM 01040917 ensures smooth penetration, reduced drag, and clean cutting edges, especially when processing leather, rubber, textiles, and synthetic materials.

Compatible with Atom digital and flatbed cutting machines, this blade is a reliable replacement oscillating knife blade for multi-material cutting applications.
